E-FAT
CZJB-135CZT e-bike thru-axle motor
CZJB 135CZT features a reinforced axle structure, providing stronger low-speed power and a more stable start. Its fully sealed design makes it suitable for rainy conditions, dusty environments, and prolonged heavy-duty operation. Compatible with a variety of e-bike types, it is a reliable power core for urban commuting and heavy-duty ebikes.
Rated Power: 1500w
Max Torque: 120Nm
Reduction Ratio: 1:3
Position Rear
Construction Gear
Rated Voltage(V) 48/52/60/72
Rated Power(W) 1500
Weight(Kg) 7
Reduction Ratio 1:3
Max Torque(N.m) 120
Wheel Diameter(Inch) 20-28
Rated Speed(km/h) 65
Spoke Specification 36H*12G/13G
Dropout(mm) 190
Brake Type V/Disc brake
Operating Temperature(℃) -20-45
Efficiency(%) ≥82
Color Black/silver
Cable Location Shaft side left
Noise Grade(dB) ≤55db
IP Grade IP65
Drive and Freewheel 6/7S
